Description
The 2 PCS HW-064 XL4015 DC Adjustable Step-Down Module is a voltage regulator designed for efficient power conversion. It is suitable for applications where the input voltage exceeds the desired output voltage, such as in DIY power supplies and industrial equipment.
- Type: Voltage Regulator IC
- Conversion efficiency: 96%
- Features: High power, high efficiency, low ripple, power indicator, includes heat sink
- Module nature: Non-isolated step-down module (BUCK)
- Input voltage: 4-38V (maximum input voltage should not exceed 38V)
- Output voltage: 1.25-36V continuously adjustable
- Output current: 0-5A
- Output power: 75W
- Working temperature: -40 to 85 degrees Celsius
- Working frequency: 180KHz
- Wiring mode: Welding, V-IN is input, V-OUT is output
- Load regulation rate: Measured at input 24V, output 12V, load changes from 1 to 4.5A
- Voltage adjustment rate: When output is 12V at 4A, voltage changes from 18-32V
- Short circuit protection: Current limit at 8A
- Over-temperature protection: Automatically shuts off output after over-temperature
- Installation method: 2 x 3mm screws
- Application range: Suitable for step-down applications where input voltage is higher than output voltage, including batteries, power transformers, and adjustable power supplies
- Dimensions: 54 x 23 x 15 mm
